Specification:

Specification	Single Mode	Multi Mode
Insertion Loss	≤0.3dB	≤0.3dB
Return Loss	PC≥45dB UPC≥55dB APC≥65dB	--
Pressure Resistance		≧80kg
Operating Temperature	-20℃-+75℃
Tensile Resistance	Branch Cord	10kg
	Main Cord	30kg
Outer Dia.	Branch Cord	2.8±0.1mm
	Main Cord	5.0±0.1mm
Jacket Material	TPU
Jacket Color	Black
Cable Length	Customized length available upon request

Important Parts:
Type of connector: LC/UPC or LC/APC
Core Options: Single-mode OS2, Multimode OM3/OM4
Cable Structure: Tactical tight-buffered or loose-tube armored fiber with a strong PU or TPU outer jacket
Fiber Count: You can choose from 2, 4, 6, 12 cores or make your own.
Deployment: Made for broadcasting outside, communicating on the go, and setting up temporary data links
Environmental Performance: Works in a wide range of temperatures, from -40 to +70 degrees Celsius, is water-resistant, and is resistant to UV rays.
Durability: It can withstand crushing, abrasion, and high tensile strength.
Options for Customization
Length of cable (up to 1000m per reel)
Material for the jacket: TPU, LSZH, PU, or PE
Color of the jacket: black, yellow, or custom on request
Type of fiber: OM3, OM4, OM5, and OS2
Polish for connectors: UPC/APC
Plastic, metal, or foldable lightweight drums are the types of drums.
You can get labels and logos printed.
What we can make
Production Lines: 12 assembly lines just for fiber cables
Daily Capacity: Up to 2,000 cable assemblies every day
Lead Time: Normal production takes 5 to 7 business days.
Standards for quality: RoHS, REACH, IEC, and GR-326
Packaging: Each item has its own label, and there are cable drums and shockproof export boxes.

Testing and certification by a third party
All Hiphotonics patch cables are checked 100% visually and physically before they are sent out. Internationally known labs (like SGS, TÜV, or BV) can give you third-party certificates and reports on insertion loss, return loss, and environmental durability if you ask for them.
Insertion Loss: < 0.3 dB (normal)
Return Loss: UPC: 50 dB or more; APC: 60 dB or more
Test Reports: Each batch comes with one.
Uses
OB vans and live event streaming
Military communications that can be used in the field
Mobile base stations and emergency command
Temporary outdoor FTTH/FTTA connections
Communication for disaster recovery and rescue

Why choose Hiphotonics?
Hiphotonics has been in business for more than 21 years and is ISO 9001 certified and approved by other countries. They make high-quality fiber optic communication systems. Our quick lead times and flexible OEM/ODM service keep customers happy in more than 80 countries.
Please get in touch with us for detailed datasheets or a custom quote.
