Low Insertion Loss: The pre-terminated cables have low insertion loss, which means that the signal won't get worse and the data will be sent in excellent quality.
High Return Loss: These cables are made to keep high return loss, which means they reduce signal reflections and keep communication links stable.
2. Strong Build:
Durable Materials: These cables are made of high-quality materials that can stand up to hard situations like extreme temperatures, dampness, and UV light.
Armored Protection: Some models come with armored protection, which makes them more durable and less likely to get damaged.
3. Simple to set up:
Pre-terminated fiber connectors: These cables come with connectors that are already connected, making installation easier and cutting down on the requirement for field terminations and splicing.
Plug-and-Play: The plug-and-play design makes it easy and quick to set up, which saves a lot of time and money on installation.
4. Flexibility:
Multiple Connector Types: Comes with multiple types of connectors, like LC, SC, and MPO, to satisfy the needs of different networks.
Different lengths: Available in different lengths to fit different installation needs and setups.
| Parameters | Test Condition | Value Multimode | Value(dB) Singlemode |
|---|---|---|---|
| Insertion Loss | 0.85/1.3um or 1.31/1.55um | ≤0.3 | ≤0.3 |
| Return Loss | 0.85/1.3um or 1.31/1.55um | ≥35 | ≥50 (APC≥60) |
| Interchangeability | Connect Randomly | <0.2<> | <0.2<> |
| Vibration | 5~50Hz, 1.5mm Amplitude | <0.1<> | <0.1<> |
| Tensile Strength | 0~15Kgf (0.9mm Exception) | <0.1<> | <0.1<> |
| High Temperature | +85°C,During 100 Hours | <0.2<> | <0.2<> |
| Low Temperature | -40°C,During 100 Hours | <0.2<> | <0.2<> |
| Temperature Cycle | -40°C~+85°C,during 5 Cycles | <0.2<> | <0.2<> |
| Humidity | +25°C~+65°C,93%R.H, 100 hours | <0.2<> | <0.2<> |
