Applications: - Industrial data links for factory automation and plant control - Intra-system links, Board-to-board, Rack-to-rack - Telecommunications switching systems - Computer-to-peripheral data links, PC bus extension - Proprietary LANs - Digitized Video - Medical instruments - Reduction of lightning and voltage transient susceptibility - High voltage isolation Features: - Compatible with Agilent Versatile Link Family of Connectors and Fiber Optic Components - 1mm Diameter Plastic Optical Fiber (POF) in Two Grades: Low Cost Standard POF with 0.22dB/m Typical Attenuation, or High Performance Extra Low Loss POF with 0.19dB/m Typical Attenuation
0755-27662758
sales@hiphotonics.com
| Specifications： | |
| Parameter | Value |
| Insertion Loss | ≤1.0dB |
| Interchangeability | ≤0.5dB |
| Typical Attenuation | 0.20dB/m (Wavelength：650nm) |
| Refractive Index | Step Index |
| Minimum Bend Radius | 25mm |
| Angle of incidence | 60° |
| Tensile Strength | ≤0. 5dB (0～80N) |
| Vibration | ≤0. 5dB 5～50HZ, 1.5mm Amplitude) |
| Numeral Aperture | 0.50 |
| Jacket Color | Black |
| Fiber Diameter | 1mm |
| Outside Diameter | 2.2mm |
| Fiber Material | PMMA |
| Operating Temperature | -40℃～+85℃ |
| Storage Temperature | -40℃～+85℃ |
