mini single dual stage isolator

0755-27662758

sales@hiphotonics.com

Send Inquiry
Download

Hiphotonics's Mini Single Dual Stage Isolator Fiber Optic Amplifiers use specific technology to make them as small as possible while still meeting the needs of EDFA and other modules. These little isolators have minimal insertion loss and very low polarization dependent loss (PDL), which makes sure that the signal is sent at a high quality. They also have low polarization sensitivity, which makes them good for a wide range of fiber optic instruments.

OIS Series		Single			Stage	Dual	Stage
		P Grade		A Grade		P Grade		A Grade
Operating wavelength Bandwidth	nm nm	1310, 1480 or 1550
		±15				±30
Typ. Isolation	dB	≥40			≥36	≥50			≥48
Min. Isolation	dB	≥32			≥30	≧46			≧43
Typical Insertion Loss	dB	0.4			0.6	0.65			0.7
Max. Insertion Loss	dB	0.55			0.7	0.75			0.8
Return Loss (In/Out)	dB	60/55			60/55	60/55			60/55
PDL Loss	dB	0.05			0.1	0.1			0.15
PMD	dB		0.15				0.05
Operating temperature	℃	-5~+70
Storage temperature	℃	-40~+85
Fiber type		Corning SMF-28
Max. Optical power	mW	500
Package dimension	mm	￠3.0 x L26

These small isolators come with WDM systems, an optical patch that doesn't use glue, and other advanced features to make sure they work well and last a long time. These micro isolators are small and compact, so they can be used in a wide range of situations where space is tight.

The company makes sure that all of its goods satisfy industry standards by putting them through strict dependability tests. The company also lets clients test samples for free, so they can see how good their products are before they buy them..

The company not only sells high-quality goods, but it also ships them quickly. The company can make up to 700 pieces a day and ship them via air. The company is a great partner for customers looking for trustworthy fiber optic solutions because they offer a wide selection of products and services.

The tiny single dual stage isolator from Hiphotonics Company has a high production capacity. It was made in our highly specialized clean room. We are sure of the quality of all of our items because they have all passed reliability tests. We give our consumers free samples so they may see how well they work for themselves. Call us today to get your free trial sample.
