3Port Opitc fiber Circulator

0755-27662758

sales@hiphotonics.com

The three-port optical circulator from Hiphotonics is a space-saving and effective tool for one-way optical signal routing. It finds extensive use in many optical communication systems, including dispersion compensation systems, fiber-optic amplifiers, and metropolitan area networks.

3PORT-CIR Series Min Typical Max Unit
Operating Wavelength Range 1310 1290～1330 nm
C Band 1525～1570
L Band 1570～1610
C+L Band 1525～1610 nm
Insertion Loss(1→2or2→3@SOP, exclude connectors) 1310,C or L 0.5 0.7 dB
C+L Band 0.7 0.9 dB
Polarization Dependent Loss(PDL) 1310,C or L 0.1 dB
C+L Band 0.2 dB
Polarization Mode Dispersion(PMD) 1310,C or L 0.06 ps
C+L Band 0.1 ps
Insertion (2→1or3→2@SOP) 1310,C or L 38 dB
C+L Band 32 dB
Return Loss dB
Directivity(1→3) 50 dB
Chromatic Dispersion 3 ps/nm
Operating Power 500 mW
Operating Temperature 0 to +70 ℃
Storage Temperature -40 to +85 ℃
Fiber Type Corning SMF-28
Color Code Port1:black;Port2&3:clear
Package Dimensions 250Um Bare Fiber P1￠5.5x50 / ￠5.5x38 mm
900Um loose tube P2￠5.5x55.0 mm
<br/>Because of its compact design, the 3-port optical circulator is well-suited for incorporation into preexisting optical systems. Its diminutive stature belies its ability to facilitate the efficient transmission of optical signals over great distances by means of high-quality optical amplification with minimal insertion loss. <br/> <br/> The capacity to dynamically equalise gain is a crucial characteristic of the 3-port optical circulator. This ensures steady and dependable signal delivery by adjusting the signal strength across all optical channels. This device is perfect for use in labs since it is dependable, has low insertion loss, and is very steady; it also has great dispersion correction.

Because of its compact design, the 3-port optical circulator is well-suited for incorporation into preexisting optical systems. Its diminutive stature belies its ability to facilitate the efficient transmission of optical signals over great distances by means of high-quality optical amplification with minimal insertion loss.

The capacity to dynamically equalise gain is a crucial characteristic of the 3-port optical circulator. This ensures steady and dependable signal delivery by adjusting the signal strength across all optical channels. This device is perfect for use in labs since it is dependable, has low insertion loss, and is very steady; it also has great dispersion correction.
<br/>In addition to removing the possibility of unwanted optical signal interference, the three-port optical circulator provides strong channel isolation. Because of this, the device is highly suitable for applications where a single fiber-optic cable is used to transmit numerous optical channels.<br/> <br/> The 3-port optical circulator has an optical channel that is epoxy-free, allowing for more personalisation and flexibility. As a result, optical systems of varying sizes and configurations are more easily integrated.<br/> <br/> The 3-port optical circulator has numerous advantages due to its adaptability and efficiency. It is perfect for a wide range of optical communication and R&amp;D applications because to its compact package size, strong channel isolation, dependable operation, dynamic gain equalisation, minimal insertion loss, and excellent optical amplification.

In addition to removing the possibility of unwanted optical signal interference, the three-port optical circulator provides strong channel isolation. Because of this, the device is highly suitable for applications where a single fiber-optic cable is used to transmit numerous optical channels.

The 3-port optical circulator has an optical channel that is epoxy-free, allowing for more personalisation and flexibility. As a result, optical systems of varying sizes and configurations are more easily integrated.

The 3-port optical circulator has numerous advantages due to its adaptability and efficiency. It is perfect for a wide range of optical communication and R&D applications because to its compact package size, strong channel isolation, dependable operation, dynamic gain equalisation, minimal insertion loss, and excellent optical amplification.
